450C Tire Inflation Rates | ||
Begin/End PSI | 31" X 10.5" | |
0 To 30 PSI | 4 Min. 05 Sec. | |
15 To 30 PSI | 2 Min. 10 Sec. | |
Begin/End PSI | 33" X 12.5" | |
0 To 30 PSI | 5 Min. 30 Sec. | |
15 To 30 PSI | 2 Min. 50 Sec. | |
Begin/End PSI | 35" X 12.5" | |
0 To 30 PSI | 6 Min. 55 Sec. | |
15 To 30 PSI | 3 Min. 30 Sec. |
Performance Data | |||||
PSI | CFM | AMP | BAR | LPM | AMP |
0 | 1.66 | 11 | 0 | 47.0 | 11 |
10 | 1.55 | 12 | 1.0 | 42.0 | 13 |
20 | 1.41 | 13 | 2.0 | 38.5 | 14 |
30 | 1.34 | 15 | 3.0 | 36.5 | 16 |
40 | 1.31 | 16 | 4.0 | 34.0 | 17 |
50 | 1.27 | 16 | 5.0 | 30.5 | 18 |
60 | 1.18 | 17 | 6.0 | 28.0 | 18 |
70 | 1.09 | 18 | 7.0 | 26.5 | 19 |
80 | 1.04 | 18 | 8.0 | 25.0 | 19 |
90 | 0.97 | 18 | 9.0 | 23.0 | 18 |
100 | 0.94 | 19 | 10.0 | 21.0 | 18 |
110 | 0.90 | 19 | |||
120 | 0.86 | 19 | |||
130 | 0.81 | 18 | |||
140 | 0.76 | 18 | |||
150 | 0.72 | 18 |
