XD Bumper Shackle Mounts


(click image for large view)

Our Xtreme-duty bumper shackle mounts fit every make of off-road bumper including brand-name bumpers (ARB, TJM), and custom-made bumpers. Without question, the strongest add-on recovery point you can buy.
The recommended solution for vehicles without bumper-integrated recovery points, or solid frame-mounted recovery points (Factory tie-downs are not recovery points).
Grade 8 mounting hardware included.

Sold in pairs or singles.
Semi-gloss finish.
3 Ton working load.
Use on front or rear bumpers.
3" X 2" bolt pattern.
4" X 3" outer dimensions.
Includes 1/2" Grade 8 hardware.
Accepts our 3/4" D-shackles.
D-shackles sold separately.

Note: Use only on a well-made steel bumper. For bumpers thinner than 3/16" steel, we recommend using a backing plate slightly larger than the dimensions of the shackle mount behind the off-road bumper when bolting on the shackle mount. See our backing plates below.

U.S. SHIPMENTS (CONTINENTAL U.S.)
Pair


Single




Backing Plates


(click images for large view)

For bumpers thinner than 3/16" steel, we recommend using our backing plate, which is 1/4" larger than the dimensions of the shackle mount. The plate has the same bolt pattern, and mounts behind the off-road bumper when bolting on the shackle mount.

The plates are shipped ready to be painted. Here it is pictured with grey primer.

Sold in pairs or singles.
Ready-to-be-painted finish.
1/4" thick steel.
Use on front or rear bumpers.
3" X 2" bolt pattern.
1/4" wider than shackle mount.
Accepts our Bumper Shackle Mounts.

Note: Use only on a well-made steel bumper.

U.S. SHIPMENTS (CONTINENTAL U.S.)
Pair - $19.95

Single - $11.95



Order with D-Shackles


XD Shackle Mounts w/ Backing Plates


(click image for large view)

See descriptions of our Bumper Shackle Mounts and Backing Plates in the sections above.

Note: Use only on a well-made steel bumper. For bumpers thinner than 3/16" steel, we recommend using a backing plate slightly larger than the dimensions of the shackle mount behind the off-road bumper when bolting on the shackle mount. See our backing plates above.
U.S. SHIPMENTS (CONTINENTAL U.S.)
Pair


Single





Weld-on Shackle Mounts

Weld-on bumper shackle mounts for your custom off-road bumper. Fits any standard 4x4 3/4" D-shackle.

4x4 D-Ring Shackles

3/4" screw pin anchor shackles fit our bumper shackle mounts. U.S. and import equally rated. All sizes available.


Re-Sellers Welcome
We are exclusive distributors for many of our listed products. We offer volume discounts, or drop-ship set-ups to retailers of 4x4 accessories and recovery gear.


Disclaimer. Please read: The effectiveness of this equipment is directly related to the manner in which it is installed, used (for off-road use only), and/or maintained. Proper installation, use and maintenance is solely the responsibility of the installer/user, and will not be assumed by OKoffroad.com.


Customer Service
Randy Ellis is having too much fun!

"I just wanted to let you know that the products I ordered rock! I have put the shackle mounts and shackles to the test without a problem. Thanks for a A+ product."

Randy Ellis
Luling, Texas



From Austin TX, Mike Sasser's FJ w/ Xd Shackle Mounts, Crosby Shackles, & SP Fairlead

"I had a ton of FJ guys with ARB bumpers comment about the shackle mounts at the FJ Summit. We did a recovery of a CJ on the trail one day and used one of the mounts to hook up the strap and it was rock solid. I used your backing plates to mount them and they are very stout. Have a good one."
